MC-3.5 ALUMINIUM CONDUCTOR XLPE INSULATED ARMOURED POWER CABLE
(A2XFY) 650/1100V AC – IS 7098-Part 1
Application
A2XFY MC-3.5,Stranded compacted aluminium conductor ,XLPE insulated, PVC inner sheathed, Galvanised Steel Flat strip armour and
PVC sheathed confirming to IS 7098-1 is suitable for AC single phase or three phase (earthed or unearthed) systems with rated voltage
up to and including 1100 V.
This cable is also suitable for DC systems with rated voltage up to and including 1500 V to earth.
Voltage Rating
650/1100 V
Standard And References
IS 8130:2013 | IS 5831:1984 | IS 3975:1979 | IS 7098-1:1988
Operation Temperature
Max.: 90˚C
Short circuit temperature 250˚C
Compliance
Conductor resistance – IS 8130:2013
Insulation resistance – IS 7098-1:1988
Flammability test – IEC 60332-1-2:2015
Core Identification
Red / Yellow / Blue / Black
Bending Radius
Fixed installation | 12 x Overall diameter
Construction
- Stranded plain compacted sector shaped copper conductor as per IS 8130, class 2
- Insulated with Cross Linked Polyethylene (XLPE) to IS 7098-1
- Extruded inner sheath with PVC Type ST2/FRLS/FR/LSZH-
- Armoured with Galvanised Flat Steel Strip to IS 3975-
- Sheathed with Extruded PVC Type ST2/FRLS/FR/LSZH
